13inch 5000W Single Shaft Hub Motor With Detached Rim

QS273 13inch 5000W 273 45H V2 Detachable Single Shaft Hub Motor

Motor Specification:

1. Motor Type: BLDC Hub Motor with Permanent Magnet
2. Motor design: Single axle out with 13inch detachable Rim
3. Rim Size: 3.5×13
4. Magnet Height:45MM
5. Pole Pairs: 28 pairs
6. Rated Power: 5000W
7. Peak Power: 10000W
8. Rated Voltage: 72V
9. Speed: 120km/h
10. Max No-load RPM: 1400RPM
11. Max Torque: 277N.M
12. Max Efficiency: 90%
13. Continious current:80A
14. Max current:120A (Peak 170A in short time)
15. Brake type: Disc brake
16. Winding Holder material: Aluminium
17. Cross Section of Phase wire: 16 mm2
18. Hall sensor phasing angle: 120 degree
19. Temperature Sensor: KTY83-122
20. Working Temperature: 70-120 degree, Peak 150 degree
21. Waterproof Grade: IP67
22. Color: Black
23. W./ G..W. : 25kgs /26kgs
24. Package Size: 44*43*34CM
