10inch hub motor 2000W

10inch 2000W 3 E-Scooter In-Wheel Hub Motor

10inch E-Scooter In-Wheel Hub Motor(45H) 2000W V3 Type



10inch 2000W Hub Motor specially designed for electric scooters, drum brake or disc brake type can be optional, speed can be customized from 40-90KMPH.



Motor Specification:



  1. Motor Type: BLDC Hub Motor with Permanent Manget
  2. Motor design: Double axle out with 10inch rim
  3. Rim size:2.15-10
  4. Matached Tire: 3.0-10, 3.5-10
  5. Magnet Height: 45MM
  6. of Pole Pairs: 16 paris
  7. Rated Power: 2000W
  8. Peak Power: 4000W
  9. Rated Voltage: 72V( 48-96V Can be optional)
  10. Speed Options:
  11. Max No-load RPM: 1250RPM
  12. Max Torque: 150N.M
  13. Max Efficiency: 90%
  14. Continious current:30A
  15. Max current:80A (Peak 100A in short time)
  16. Brake type: Disc brake or Brum brake(Optional)
  17. Rear Fock width for installation: 200mm
  18. Cross Section of Phase wire: 10 mm2
  19. Hall sensor phasing angle: 120 degree
  20. Temperature Sensor: Optional
  21. Working Temperature: 70 degree, Peak 120 degree
  22. Waterproof Grade: IP66
  23. Color: Black or Silver
  24. W./ G..W. : 11kgs / 12kgs
  25. Package Size: 34*34*33CM
