2000W Electric Bike Spoke Hub Motor with drop-out 150mm

The E-bike spoke hub motor specially designed for high power electric bike or bicycle rated power can be customized 2000Wor 3000W, max speed 45-90km/h,and the motor installation width for the rear fock is 150mm,and can be attached the E-bike Sprocket and Brake disc!

Motor Specification:

  1. Motor Type: BLDC Hub Motor with Permanent Magnet
  2. Motor design: Double axle out
  3. Spoke hole: 3.4mm x 36pcs
  4. Matching Rim:16inch-26inch
  5. Magnet Height: 50MM
  1. Pole Pairs: 23 paris
  2. Rated Power: 2000W
  3. Peak Power: 4000W
  4. Rated Voltage: 72V( 48-96V Can be optional)
  5. Speed: 60km/h (30-65km/h can be customized)
  6. Max No-load RPM: 850RPM
  7. Max Torque: 140N.M
  8. Max Efficiency: 88%
  9. Continious current:30A
  10. Max current:80A (Peak 100A in short time)
  11. Brake type: Disc brake
  12. Rear Fork width for installation: 150mm
  13. Winding Core material: Aluminium
  14. Cross Section of Phase wire: 10 mm2
  15. Hall sensor phasing angle: 120 degree
  16. Temperature Sensor: Optional
  17. Working Temperature: 70 degree, Peak 120 degree
  18. Waterproof Grade: IP54
  19. Color: Black
  20. W./ G..W. : 14kgs / 15kgs
  21. Package Size: 34*34*33CM

Motor Drawing,



%e7%85%a7%e7%89%87-005 %e7%85%a7%e7%89%87-006
