QS205 2000W 12inch E-Car Hub Motor

Category: .

QS205 2000W 12inch Single shaft Out E-Car Hub Motor (50H) V2 Type



 Motor Specification:

  1. Motor Type: BLDC Hub Motor with Permanent Magnets
  2. Motor design: Single axle out with 12inch Aluminium rim
  3. Rim size:3.5×12
  4. Matching Tire: 130/70-12
  5. Magnet Height: 50MM
  6. Pole Pairs: 23 paris
  7. Rated Power: 2000W
  8. Peak Power: 4000W
  9. Rated Voltage: 72V( 48-96V Can be optional)
  10. Speed: 65km/h (30-70km/h can be customized)
  11. Max No-load RPM: 850RPM
  12. Max Torque: 140N.M
  13. Max Efficiency: 88%
  14. Continious current:30A
  15. Max current:80A (Peak 100A in short time)
  16. Brake type: Disc brake
  17. Cross Section of Phase wire: 8 mm2
  18. Hall sensor phasing angle: 120 degree
  19. Temperature Sensor: Optional
  20. Working Temperature: 70 degree, Peak 120 degree
  21. Waterproof Grade: IP54
  22. Color: Black
  23. W./ G..W. : 15kgs / 16kgs
  24. Package Size: 44*43*34CM
