QSMotor 12inch 1000W Drum Brake Hub Motor

QS260 12inch E-Scooter Hub Motor(27H) 1000W V1 Type

Motor Specification:

1. Motor Type: BLDC Hub Motor with Permanent Magnet
2. Motor design: Double axle out with 12inch rim
3. Rim size:3.5×12,2.5×12
4. Matching Tire: 120/70-12, 130/70-12
5. Magnet Height: 27MM
6. Pole Pairs: 24 pairs
7. Rated Power: 1000W
8. Max Power: 1600W
9. Rated Voltage: 48V,60V,72V
10. Speed: 45-50KPH
11. Max No-load RPM: 600RPM(Can be customized)
12. Max Torque: 110N.M
13. Max Efficiency: 86%
14. Continious current:25A
15. Max current:45A
16. Brake type: Disc brake or drum brake
17. Rear Fork width for installation: 200mm
18. Cross Section of Phase wire: 4 mm2
19. Hall sensor phasing angle: 120 degree
20. Temperature Sensor: Optional
21. Working Temperature: 70 degree, Peak 120 degree
22. Waterproof Grade: IP67
23. W./ G..W. : 15kgs / 16kgs
24. Package Size: 44*43*34CM
